Product Details
＋
Product Specification
| Brand | Smart IVR |
| Usage/Application | CCTV Recorder |
| Smart Phone Support | Windows |
| Color | Black |
| Power Source | Electric |
| Camera Style | Dome Camera |
| Vision Type | Day |
| Features | Humanoid Detection, Vehicle Detection, Face Detection |
| Model | ID-1-16-A |
| Video and Audio | |
| IP Camera Input | 8 Channel |
| Audio Input/ Output | 1 Channel Output, RCA; Audio output support HDMI |
| Display | |
| Interface | 1 HDMI, 1 VGA |
| Resolution | HDMI: 1024×768, 1280×800, 1280×1024, 1440×900, 1920×1080@60 VGA: 1024×768, 1280×800, 1280×1024, 1440×900, 1920×1080@60 |
| Max Decoding | 4ch@ 5.0MP 25fps,4ch@1080P 25fps |
| Multi-screen Display | 1/8 |
| OSD | Camera Name & Time, Recording, Alarm Detecting, Remote connection, Volume, Channel Number |
| Recording | |
| Compression | H.265/H.264 |
| Resolution | 8ch 5.0MP/4.0MP/1080P/960P/720P |
| Record Mode | Manual, Schedule, MD |
| Video Detection and Alarm | |
| Trigger Events | Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer |
| Video Detection | Motion Detection, No Video Detection |
| Playback and Backup | |
| Sync Playback | 4ch 5.0MP, 8ch 4.0MP, 8ch 1080P/960P/720P |
| Search Mode | Time /Date, Schedule, Motion Detection |
| Playback Function | Day View, Hour View, Back Step, Rewind, Pause, Play, Fast Forward, Slow, Step, Full Screen, Snap, Sound On/Off, Zoom |
| Backup Mode | USB Device/Network |
| Network | |
| Interface | 1 RJ-45 port (10/100Mbps) |
| Network Function | TCP/IP, DHCP, UDP, SMTP, NTP |
| Smart Phone | iPhone, Android |
| Interoperability | ONVIF 2.4 |
| Storage | |
| SATA | 1 SATA interface |
| Capacity | up to 6TB |
| General | |
| Power Supply | 12V DC |
| Consumption | ≤ 10 W (Without HDD) |
| Working Temperature | -100C~ 550C |
| Working Humidity | 10 % ~ 90 % |
| Dimensions | 200×200×45mm |
| Weight | ≤ 1.2kg (Without HDD) |
