Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | BES 516-326-BO-C-05 |
| Approvals | CE |
| Cable Diameter | 4.6 mm |
| Cable Jacket Material | PVC |
| Cable Length | 5 m |
| Dropout Voltage | 1.5 V |
| Housing Material | Brass |
| Hysteresis | 0.15 |
| Mounting Type | Flush |
| Number of Conductors | 3 |
| Output | PNP |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Shielding | Shielded |
| Switch Function | Normally open (NO) |
| Temperature, Ambient | 70 °C |
| Tolerance | ±10 % |
| Torque | 35 Nm |
| Vibration | 55 Hz, 1 mm ampl., 3x30 min |
| Voltage, Operating | 24.0 V |
Overview
Our standard inductive sensors are ideal for object detection in metal areas. Here, they are suitable for a multitude of applications.
Because they work without contact, they are wear-free and very resistant to dirt. The sensors are also short-circuit-proof. We provide the inductive standard sensors in configurations from Φ 3 mm to 80 × 80 mm square dimensions.
